Empalmadora por fusión de fibra de gran diámetro Laser Source S400 LDF

La cortadora de fibra óptica de gran diámetro SH-D105 se puede utilizar principalmente para cortar fibras de gran diámetro y combinadores de fibra óptica. Los usuarios pueden cortar fácilmente diferentes tipos de fibras ópticas y combinadores configurando la fuerza de tracción de la fibra óptica e impulsando la cuchilla con anticipación. La máquina no solo tiene la estabilidad de corte necesaria para la producción, sino que también tiene las características de depuración flexible necesarias para la investigación y el desarrollo. Características : Aplicable a   fibras de diámetro de revestimiento de 60 μm ~ 400 μm Admite definición de parámetros y actualización de software. Bomba de vacío con ranura en V conveniente para colocar fibra Hoja duradera , vida útil de más de 15000  veces. Suministre 2 soportes de fibra diferentes (se aplican a 60 µm ~ 400 µm) Adecuado para cortar diversas fibras, como fibra de cristal fotónico, fibra dopada, tubo de vidrio y tubo capilar.

T0X series optical fiber recoater is the latest high-precision optical fiber recoater, including four types (HXGK-T01---HXGK-T04), suitable for various types of ordinary fiber, ribbon fiber and polarization maintaining fiber. Products are well-crafted with stable quality and easy to operate. They have a wide range of applications in scientific research, fiber optic sensing, fiber optic gyroscopes, optical switches, fiber optic lasers, fiber optic communications, etc. They are designed as multi-functional coating machines for fiber optic recoating repair. The coating length of this optical fiber recoater is 50 mm or 100 mm (customizable type), used to repair the outer coating layer of fusion-spliced optical fibers, to restore the physical and optical characteristics of the fibers, and to enhance the flexibility of the fibers to protect the bare fiber and fusion point.

SH-D105 large diameter optical fiber cleaver can be mainly used for cutting large diameter fibers and optical fiber combiner. Users can easily cut different types of optical fibersand combiners by setting the pulling force of the optical fiber and propelling the blade in advance. The machine not only has the cutting stability needed for production, but also has the characteristics of flexible debugging needed for research and development.

1. Six motor core to core, core adjustment, center alignment 2. Artificial calibration and Real-time ARC automatic calibration are optional. 3. The same optical fiber and different opticalfibers are connected in the center. 4.Electrical discharge ARC makes realtime compensationaccording to the pressure, environment and temperature parameter. 5.Two cameras can observe X axes and Y axes at the same time. 6. High resolution 5 inch color LED touch screen, multi languages are customizable. 7.2 USB ports: one for data transmission,one for power supply of LED light

Special wavelength OTDRs are reliable instruments used to measure the characteristics of optical fibers with large core diameters.This series of products are compact, light transmission quality and achieves the measurement results after the results processing,archiving, printing. The person who installs and maintains the fiber optic cable by looking at the "incident point"of fiber optic test graph to point out these irregularities in the fiber, locate the positions, measure the attenuation and the uniformity of damage and attenuation.

1.Easy to use,automatically longitudinal strip,high quality striping,stable and efficient 2.The blade is durable and easy to replace 3.Adopt high-precision linear guide and motor directly drive striping way to ensureno damage to the fiber google is broken

Main features: 1.it is composed ofoptical fiber endingalignmentsystem and optical fiber welding machine. 2.independent optical fiber endingalignment by manual is conwenient and fast 3.Applicable to all kinds of polarization-maintaining optical fibers. 4.Applicable to various coated optical fibers.

Clásico de fibra de empalme de la máquina. 4.3-pulgadas de pantalla táctil, tamaño pequeño, fácil de llevar. Resistente al polvo, resistente al agua, resistente a los golpes, mayor adaptabilidad medio ambiente .
